Isotron Equipment
Chillers
Isotron partners with SMC to supply chillers in various sizes and cooling capacities to meet the needs of industrial operations.
Compact Chillers
| Size | Model | Rated Capacity | Process Pump | Reservoir | Refrigerant | Weight (kg) | Operating Temperature Range | Temperature Stability | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kW | kcal/h | btu/h | TR | l/min | mca | Liters | |||||||
| Compact | HRS012 | 9,5 | 8170 | 32444 | 2,70 | 45 | 50 | 18 | R410A (HFC) | 130 | 5 à 40 °C | ± 0,1 °C | |
| HRS018 | 10,5 | 12470 | 35859 | 2,99 | 45 | 50 | 25 | R410A (HFC) | 180 | 5 à 40 °C | ± 0,1 °C | ||
| HRS024 | 15,7 | 13502 | 53859 | 4,46 | 45 | 50 | 42 | R410A (HFC) | 215 | 5 à 35 °C | ± 0,1 °C | ||
| HRS030 | 20,5 | 17630 | 70011 | 5,83 | 45 | 50 | 42 | R410A (HFC) | 215 | 5 à 35 °C | ± 0,1 °C | ||
| HRS050 | 25 | 21500 | 85379 | 7,11 | 125 | 80 | 60 | R410A (HFC) | 280 | 5 à 35 °C | ± 0,1 °C | ||
| HRS060 | 28 | 24080 | 95625 | 7,96 | 125 | 80 | 60 | R410A (HFC) | 280 | 5 à 35 °C | ± 0,1 °C | ||
Medium-Sized Chillers
| Size | Model | Rated Capacity | Process Pump | Reservoir | Refrigerant | Weight (kg) | Operating Temperature Range | Temperature Stability | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kW | kcal/h | btu/h | TR | l/min | mca | Liters | |||||||
| Medium-Sized | HRS090 | 9 | 7738 | 30709 | 2,56 | 45 | 50 | 18 | R407C (HFC) | 130 | 5 à 35 °C | ± 0,5 °C | |
| HRS100 | 9,5 | 8170 | 32444 | 2,70 | 56 | 50 | 18 | R407C (HFC) | 171 | 5 à 35 °C | ± 1,0 °C | ||
| HRS150 | 14,5 | 12470 | 49520 | 4,12 | 56 | 50 | 18 | R407C (HFC) | 177 | 5 à 35 °C | ± 1,0 °C | ||
Large-Scale Chillers
| Size | Model | Rated Capacity | Process Pump | Reservoir | Refrigerant | Weight (kg) | Operating Temperature Range | Temperature Stability | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kW | kcal/h | btu/h | TR | l/min | mca | Liters | |||||||
| Large-Scale | HRS012 | 1,3 | 1118 | 4440 | 0,37 | 7 | 19 | 5 | R407C (HFC) | 40 | 5 à 40 °C | ± 0,1 °C | |
| HRS018 | 1,9 | 1634 | 6489 | 0,54 | 7 | 19 | 5 | R407C (HFC) | 45 | ||||
| HRS024 | 2,4 | 2064 | 8196 | 0,68 | 7 | 19 | 5 | R407C (HFC) | 46 | ||||
| HRS030 | 3,2 | 2752 | 10929 | 0,91 | 7 | 19 | 5 | R407C (HFC) | 47 | ||||
| HRS050 | 5,1 | 4386 | 17417 | 1,45 | 28 | 50 | 5 | R410A (HFC) | 69 | 5 à 40 °C | ± 0,1 °C | ||
| HRS060 | 5,9 | 5074 | 20150 | 1,68 | 28 | 50 | 5 | R410A (HFC) | 73 | ||||
